Description
Microcomputer chip control technology (non-PLC) with 8.8 inch full color OLED LCD touch screen, including 30 standard procedures and 120 self-defined procedures.
LW190 laboratory glassware washer adopt variable frequency soft-start function control the circulation pump from 0-400L/min. Pipeline pressure monitor monitors the pressure of the main pipeline in real time.
LW190 adopts the back water supply method for basket and rack.
Electronic safety lock, EULA electric door opening and closing technology, the experimenter can set the door opening temperature limit.
Water heating over temperature protection, hot air heating over temperature protection, water pump over temperature protection, fan over temperature protection.
Monitoring water leakage, The instrument will stop working if water leakage;
The instrument will recovery automatically after water cut and memory if the power cut off;
The instrument have the remind function when the cleaning agent is lacking;
Multi-layer filtration system: prevent debris from entering the pipeline and causing blockage;
Technical Parameter
- Microcomputer control system
- 8.8 inch full color touch screen
- Chamber material: 316 stainless steel
- Shell material: 304 stainless steel
- Pipe material: 316 stainless steel+pharmaceutical silicone
- Circulating water volume: 400L/min
- Circulation pump with variable frequency soft-start function
- Cleaning data save with U Disk
- Printer: RS232 interface
- Peristaltic pump with double channel
- Alarm for lack of cleaning agent
- Power: 220V,50Hz
- Heating power: 4KW
- Basket design :FL-EXCH module
- EULA electric door opening and closing technology
- Water heating over temperature protection
- Hot air heating over temperature protection
- Water pump over temperature protection
- Fan over temperature protection
- Monitoring water leakage
- Peristaltic pump:2
- Air volume: 55m3/h
- Number of users:3
- Three level authority
- Chamber volume:185L
- Inner Dimensions:546mm(L)*545mm(W)*623mm(H)
- External Dimensions:670mm(L)*690mm(W)*940mm(H)
